The Watergate HD Swing Gate provides controlled vehicle access for car parks, laneways, private property and other restricted areas. Built from pre-galvanised steel, this heavy-duty swing gate is supplied with a safety yellow powder-coat finish as standard. Other colour options are available on request.
The gate is supplied with two latch posts: one allows the gate to be padlocked in the closed position, while the other secures it in the open position. Standard latch posts are manufactured from 90 mm diameter steel pipe. The hinge post is constructed from 140 mm or 165 mm diameter steel pipe, selected according to the gate length.
Choose a mounting method to suit the site: bolt-down, concrete in-ground, or bolt-down with a rag bolt cage. The illustrated configuration has up to 6.2 metres of open clearance and a 1,000 mm height, with a gate leaf manufactured from 75 mm square steel. For openings greater than 6.2 metres, a pair of gates meeting in the middle is recommended.
The Watergate can be configured for differing access-control applications, with alternative designs available on request. Site measurement and installation services are also available for a tailored gate installation.
- Pre-galvanised steel construction
- Safety yellow powder coat as standard
- Two latch posts for open and closed positions
- 140 mm or 165 mm diameter hinge posts
- 90 mm diameter latch posts
- Bolt-down, in-ground or rag bolt cage mounting
- Recommended paired-gate layout for openings over 6.2 m
- Site measure and installation service available
